Professional for Chain Link Fence Fabric and Parts&Metal Meshes.
High Quality,resonable price and best service
Professional for Chain Link Fence Fabric and Parts&Metal Meshes.
High Quality,resonable price and best service
 |
| Place of Origin: | Hebei |
| Brand Name: | XR |
| Certification: | ISO , CE |
| Model Number: | XR-1560 |
| Minimum Order Quantity: | 10 Sqm |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Carton Box , Wooden Case |
| Delivery Time: | 5-8 Work Days |
| Payment Terms: | T/T, Western Union, L/C |
| Supply Ability: | 2000 Sqm/Month |
| Material: | SS316 , SS304 | Wire Rope: | 1.5Mm , 1.6Mm |
|---|---|---|---|
| Mesh Type: | Ferruled | Structure: | 7x7,7x19 |
| Hole Size: | 50 X 86 Mm , 60 X 104 Mm | Dimensions: | Custom-Made In Height And Width |
| High Light: | stainless steel rope mesh netting,flexible stainless steel cable mesh |
||
Light Weight High Strength Stainless Steel Wire Rope Mesh Net
|
Hole Size (Opening) |
1.2MM(3/64) (7 x 7 ) |
1.6MM(1/16) (7 x 7 ) |
2.0MM(5/64) (7 x 7 ) |
2.4MM(3/32) (7 x 7 ) |
3.2MM(1/8) (7 x 19 ) |
| 20 x 35mm | F-1235 | ||||
| 25 x 42mm | F-1225 | F-1625 | |||
| 30 x 52mm | F-1230 | F-1630 | F-2030 | ||
| 35 x 60mm | F-1235 | F-1635 | F-2035 | ||
| 38 x 66mm | F-1238 | F-1638 | F-2038 | F-2438 | |
| 40 x 69mm | F-1240 | F-1640 | F-2040 | F-2440 | F-3040 |
| 50 x 86mm | F-1250 | F-1650 | F-2050 | F-2450 | F-3050 |
| 60 x 104mm | F-1260 | F-1660 | F-2060 | F-2460 | F-3060 |
| 70 x 120mm | F-1270 | F-1670 | F-2070 | F-2470 | F-3070 |
| 76 x 131mm | F-1276 | F-1676 | F-2076 | F-2476 | F-3076 |
| 80 x 138mm | F-1280 | F-1680 | F-2080 | F-2480 | F-3080 |
| 90 x 154mm | F-1290 | F-1690 | F-2090 | F-2490 | F-3090 |
| 100 x 173mm | F-12100 | F-16100 | F-20100 | F-24100 | F-30100 |
| 120 x 206mm | F-12120 | F-16120 | F-20120 | F-24120 | F-30120 |
Rope Mesh is manufactured from high-grade stainless steel cables of material class 1.4401, AISI316.
Mesh connections (ferrules) are available in highly aesthetic stainless steel for premium applications or where resistance to corrosion is a driving consideration.Finished diamond mesh style when it is stretched at 60 degree angle ;
Material of Wire Rope Mesh: Stainless steel 304,304L,316,306L etc.
| SS304 | (%) C:≤0.07, Si :≤1.0, Mn :≤2.0, Cr :17.0-19.0, Ni :8.0-11.0, S :≤0.03, P :≤0.035 |
| SS316 | (%) C:≤0.08, Si:≤1.00, Mn:≤2.00, P≤:0.035, S:≤0.03, Ni:10.0-14.0, Cr:16.0-18.5 |
| SS316L | (%)C:≤0.03, Si:≤1.00, Mn:≤2.00, P:≤0.045, S:≤0.030, Cr:16.0～18.0, Ni:12.0～15.0 |
Stainless steel wire rope mesh is light, robust, and transparent. High-quality stainless steel cables and pressed ferrules are used for the production of the mesh and connected to a load-bearing and flexible structure. The curvature in the opposite direction of the stainless steel cables creates the exceptionally robust characteristics of the mesh can even stand up to heavy loads.
