Home ProductsRazor Wire Concertina

450mm 500mm Coil Welded BTO22 Diamond Mesh Razor Wire Fencing Protect Residents From Thieves

450mm 500mm Coil Welded BTO22 Diamond Mesh Razor Wire Fencing Protect Residents From Thieves

450mm 500mm Coil Welded BTO22 Diamond Mesh Razor Wire Fencing Protect Residents From Thieves
video
450mm 500mm Coil Welded BTO22 Diamond Mesh Razor Wire Fencing Protect Residents From Thieves
Product Details:
Place of Origin: CHINA
Brand Name: XR
Certification: CE
Model Number: WRW
Payment & Shipping Terms:
Minimum Order Quantity: 6 Square Meters
Price: Negotiated
Packaging Details: Pallet
Delivery Time: 7-10 days after get the payment
Payment Terms: T/T, L/C, Western Union, MoneyGram
Supply Ability: 500 Tons Per Month
Contact Now
Detailed Product Description
Keyword: Welded Razor Wire Fencing Zinc Coated: Galvanized Wire:8-60g/m2;Blade:40-60g/m2 Or As Customer's Req
Material: Galvanized And Stainless Steel Mesh Aperture: 75x150Mm
Panel Size: 1x2M,2x4M,4x8M Barb Length: BTO10 12 18 22 28 30 CBT60 65
Height: 1.2/1.5/1.8/2.1/2.4M Name: 450mm 500mm Coil Welded BTO22 Diamond Mesh Razor Wire Fencing Protect Residents From Thieves
High Light:

450mm Diamond Mesh Razor Wire Fencing

,

500mm Diamond Mesh Razor Wire Fencing

,

BTO22 Diamond Mesh Razor Wire Fencing

450Mm 500Mm Coil Welded Razor Wire Fence Can Protect Residences From Thieves





Product Material



Hot-dipped galvanized core wire+stainless steel blade
Hot-dipped galvanized core wire and blade
Electro galvanized core wire and blade
PVC coated core wire and blade
Stainess steel core wire and blade



Product Feature



Anti-corrosion, aging, sunscreen, weather.
High-strength steel core very difficult to cut off.
High protection, it is almost impossible to climb.
Anti-corrosion, aging, sunscreen, weather.
Extremely simple to install, needs three to four to install molding.



Welded razor wire fence Hole Type



1. Square Hole Size:100mmx100mm,150mmx150mm,200mmx200mm.

2. Diamond Hole Size:75mmx150mm,100mmx200mm,150mmx300mm.



Peference

number

Thickness

(mm)

Wire dia

(mm)

Barb length

(mm)

Bard width

(mm)

Bard spacing

(mm)

BTO-12 0.5±0.05 2.5±0.1 12±1 15±1 26±1
BTO-15 0.5±0.05 2.5±0.1 18±1 15±1 33±1
BTO-22 0.5±0.05 2.5±0.1 22±1 15±1 34±1
BTO-30 0.5±0.05 2.5±0.1 30 18 45±1
CBT-60 0.6±0.05 2.5±0.1 60±2 32±1 100±2
CBT-65 0.6±0.05 2.5±0.1 65±2 21±1 100±2



Barbed Tape Wire Specification
Loop Outside Diameter No. of Loops Standard Length per Coil Type Notes
450mm 33 7-8M CBT-60.65 Single coil
500mm 56 12-13M CBT-60.65 Single coil
700mm 56 13-14M CBT-60.65 Single coil
960mm 56 14-15M CBT-60.65 Single coil
450mm 56 8-9m(3 CLIPS) BTO-10.12.18.22.28.30 Cross type
500mm 56 9-10M (3 CLIPS) BTO-10.12.18.22.28.30 Cross type
600mm 56 10-11M(3 CLIPS) BTO-10.12.18.22.28.30 Cross type
600mm 56 8-10M (5 CLIPS) BTO-10.12.18.22.28.30 Cross type
700mm 56 10-12M (5 CLIPS) BTO-10.12.18.22.28.30 Cross type
800mm 56 11-13M (5 CLIPS) BTO-10.12.18.22.28.30 Cross type
900mm 56 12-14M (5 CLIPS) BTO-10.12.18.22.28.30 Cross type
960mm 56 13-15M (5 CLIPS) BTO-10.12.18.22.28.30 Cross type
980mm 56 14-16M (5 CLIPS) BTO-10.12.18.22.28.30 Cross type


Product Advantage



Strong Protection;
Easy installation;
Use a long time



Product Usage



1. Concertina Razor wire can be installed in the form of barbed tape wire or concertina coil to walls or fencing.
2. Concertina Razor wire is widely used to manufacture the wire fence for a fencing system or security system.
3. Concertina Razor wire is applicable in military field,airports fencing,prisons protection,detension houses, government buildings and other national security facilities.



450mm 500mm Coil Welded BTO22 Diamond Mesh Razor Wire Fencing Protect Residents From Thieves 0450mm 500mm Coil Welded BTO22 Diamond Mesh Razor Wire Fencing Protect Residents From Thieves 1
