Architectural Metal Coil Drapery ,Aluminum Alloy Cascade Mesh Various Colors

Architectural Metal Coil Drapery ,Aluminum Alloy Cascade Mesh Various Colors

  • Architectural Metal Coil Drapery ,Aluminum Alloy Cascade Mesh Various Colors
  • Architectural Metal Coil Drapery ,Aluminum Alloy Cascade Mesh Various Colors
Architectural Metal Coil Drapery ,Aluminum Alloy Cascade Mesh Various Colors
Product Details:
Place of Origin: CHINA
Brand Name: XR
Certification: CE,SGS
Model Number: DM-012
Payment & Shipping Terms:
Minimum Order Quantity: 50 Sqm
Price: Negotiation
Packaging Details: Wooden Pallet , Wooden Case
Delivery Time: 5-8 Days After Get The Payment
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 1000Sqm/week
Contact Now
Detailed Product Description
Color: Gunmetal , Black , Bronze , Silver , Copper , Etc Product Name: Metal Coil Mesh Drapery Room Partition
Hole Size: 4 Mm , 5 Mm , 6 Mm , 8 Mm , 10 Mm Wire: 0.8 Mm , 1.0 Mm 1.2 Mm , 1.5 Mm , 1.8 Mm , 2.0 Mm
Material: Aluminum , Stainless Steel , Galvanized Wire Application: WIndow Curtain , Room Divider , Curtain Wall
Drapery: 1.5 Time And 1.0 Time Size: Customized
High Light:

decorative metal mesh panels

,

decorative mesh screen

Architectural Metal Coil Drapery Aluminum Alloy Cascade Mesh Various Colors



Product Instruction

Material Wire Dia Hole Size Weight Surface
Stainless Steel 1.0 mm 5 mm 3.3kg/m2 Natural polished
Stainless Steel 1.0 mm 6 mm 3.5kg/m2 Natural polished
Stainless Steel 1.2 mm 6 mm 5.5kg/m2 Natural polished
Al-Mg Alloy 1.2 mm 4 mm 1.9kg/m2 Paint-spray /Anodizing
Al-Mg Alloy 1.2 mm 5 mm 1.5kg/m2 Paint-spray /Anodizing
Al-Mg Alloy 1.2 mm 6 mm 1.25kg/m2 Paint-spray /Anodizing
Al-Mg Alloy 1.2 mm 7 mm 1.2kg/m2 Paint-spray /Anodizing
Al-Mg Alloy 1.2 mm 8 mm 1.13kg/m2 Paint-spray /Anodizing
Al-Mg Alloy 1.2 mm 9 mm 0.85kg/m2 Paint-spray /Anodizing
Aluminium 1.0 mm 5 mm 1.5kg/m2 Paint-spray /Anodizing
Aluminium 1.2 mm 6 mm 2.5kg/m2 Paint-spray /Anodizing
Aluminium 1.2 mm 7 mm 2.0kg/m2 Paint-spray /Anodizing
Carbon Steel 0.9 mm 6 mm 4.0kg/m2 Paint-spray /Anodizing
Carbon Steel 1.0 mm 7 mm 5.5kg/m2 Paint-spray /Anodizing
Carbon Steel 1.2 mm 8 mm 6.0kg/m2 Paint-spray /Anodizing



Metal mesh drapery is a new kind of building decoration materials, which are widely used in building elevation, room dividers, the ceiling treatment, balconies, hotels, concert halls, office buildings, exhibition halls, shopping malls,stage backdrops, showing charming effects and romantic feelings under light.

This very versatile coil drapery can be hung over windows, across an entryway, or grouped

together to partition off a room.



Specification
1. The material: We have the Aluminum alloy and the SS 304, 316,
2. The wire diameter: 0.6mm-2.0mm
3. The mesh hole: 3mm, 4mm, 5mm, 6mm, 7mm, 8mm, 9mm, 10mm, and as you need
4. The color of the mesh: We have more than hundreds of colors for your choice. You can also choose the color you favor.



Surface treatment :

1. Acid pickling:
This kind of treatment is most simple one. It mainly function is cleaning the oxide layer, and the metal curtain via this kind of treatment, the color will be the silvery white.

2. Anodic oxidation:
This one is a little complex; This one is working to enhance the rigidity and the wear-resisting property of the Al alloy. This one can color the metal curtain, and make the metal curtain more durable and beautiful.

3. Baking finish (This is the most popular one):
This kind is the simple one of coloring the metal curtain, it just paint mixing then put the metal curtain to the coating area to make the color.



Application:



We have three different installation ways: U track, H track installation and stainless steel curtain rod installation.


1. H track can be applied as rippled strips to appear the effect of fluency. Because of high flexibility, it's easy to be bent into any shape or angle in order to conform to installation position condition which you need to install with copper or brass mesh coil curtain.


2. U track is a straight structure. It's difficult to bend because of exceptional structural design and high-quality control. U track can provide a good visual hang feeling for your copper and brass mesh coil curtain. If you need and desire an aesthetic appearance, U track will be a good choice.


3. Stainless steel curtain rod is is easy for installing with copper and brass mesh coil curtain on it. You can use shorter time to compete installation.


H track, U track are made from aluminum materials. Stainless steel curtain rod material conforms to AISI 316 materials group. These three installation ways can provide ideal solutions with excellent stability, strength and flexibility for you. You can custom according to your requirements.



Characteristic :

• Light diffusion and good ventilation.
• UV resistant and flame resistant.
• Beautiful appearance and various color.
• Versatility and decorative effects.
• Aesthetic appeal and functionality.
• Finishes are beautiful and resilient.
• Color never fading and paint never dropping.
• Gorgeous and high-end.

• Durability and flexibility



Architectural Metal Coil Drapery ,Aluminum Alloy Cascade Mesh Various Colors 0Architectural Metal Coil Drapery ,Aluminum Alloy Cascade Mesh Various Colors 1



Architectural Metal Coil Drapery ,Aluminum Alloy Cascade Mesh Various Colors 2







.
